Build games with LuaJIT

Typed. GPU-driven. One data model.

Get started Modules

A cactus and an armadillo in the desert sun

Live inspection

Inspect, freeze, and edit a running game through the built-in MCP server.

ECS built for LuaJIT

An archetype-based ECS with FFI components, contiguous columns, and a dirty model the GPU reads.

Batteries included

Physics, audio, particles, text, retained UI, sequences, sprite sheets, and hot reload share the ECS.

Static typing

Teal checks component, query, system, and engine APIs before the game runs.

Install

The tecs command carries the compiler, engine, type definitions, and project template. It needs no separate Lua, LuaRocks, Teal, or C compiler installation.

macOS

brew install tecs-dev/tap/tecs

Windows

scoop bucket add tecs https://github.com/tecs-dev/scoop-bucket
scoop install tecs

Linux

brew install tecs-dev/tap/tecs

Create a game and run it:

tecs new my-game && cd my-game && tecs run

The Tecs CLI carries the project toolchain in one file. Contributors can build this repository through Cargo; getting started covers that workflow.

Entities are the interface

A drawn quad, a light, a sound, a physics body: each one is an entity carrying components, and the subsystem that cares for it finds it by query. A game holds no draw list, no voice handle and no body pointer, so what works on one of them works on all of them. A snapshot saves the scene, the profiler reports where the frame went, and the debug server inspects and edits any of it while the game runs.

The host owns the loop. An entry file returns an application, and the plugin it carries registers work instead of driving frames.

local Transform2D <const> = tecs.Transform2D
local gfx <const> = tecs.gfx

return tecs.newApplication({
    window = {title = "Spin", width = 1280, height = 720},
    ambientLight = {0.05, 0.05, 0.08},
    plugin = function(world: tecs.World, app: tecs.Application)
        -- Something on screen is an entity. Nothing issues a draw call for it.
        world:spawn(
            Transform2D.new({
                x = 640, y = 360, scaleX = 64, scaleY = 64
            }),
            gfx.Tint(0.85, 0.4, 0.3, 1.0),
            gfx.Renderable2D()
        )

        -- So is the light falling on it, placed by the same Transform2D.
        world:spawn(
            Transform2D.new({x = 520, y = 300}),
            gfx.PointLight2D(120, 600, 1.0, 0.9, 0.7, 3.0)
        )

        local movers <const> = world:newQuery({
            include = {Transform2D, gfx.Renderable2D},
        })

        world:addSystem({
            name = "game.Spin",
            phase = tecs.ecs.phases.Update,
            run = function(dt: number)
                for archetype, length in movers:iter() do
                    local transforms <const> = archetype:getMut(
                        Transform2D
                    )
                    for row = 1, length do
                        transforms[row].rotation = transforms[row].rotation + dt
                    end
                end
            end,
        })
    end,
})

ECS examples

Components

local world = tecs.ecs.newWorld()

-- Define typed components with Teal
local record Position is tecs.ecs.Component
    x: number
    y: number
    metamethod __call: function(self, x?: number, y?: number): Position
end

tecs.ecs.newFFIComponent({
    name = "Position",
    container = Position,
    fields = {{"x", "float"}, {"y", "float"}},
})

local record Velocity is tecs.ecs.Component
    x: number
    y: number
    metamethod __call: function(self, x?: number, y?: number): Velocity
end

tecs.ecs.newFFIComponent({
    name = "Velocity",
    container = Velocity,
    fields = {{"x", "float"}, {"y", "float"}},
})

-- Query and update entities
local query = world:newQuery({include = {Position, Velocity}})

world:addSystem({
    phase = tecs.ecs.phases.Update,
    run = function(dt: number, _world: tecs.World)
        for archetype, len in query:iter() do
            local positions = archetype:getMut(Position)
            local velocities = archetype:get(Velocity)
            for row = 1, len do
                positions[row].x = positions[row].x + velocities[row].x * dt
            end
        end
    end,
})

world:spawn(Position(100, 100), Velocity(10, 0))

Relationships

local world = tecs.ecs.newWorld()
local ChildOf = tecs.ecs.ChildOf

-- Create a parent entity
local parent: integer = world:spawn(
    tecs.ecs.Name("parent"), tecs.Transform2D(100, 100)
)

-- ChildOf has cascadeDelete; despawning parent despawns children too.
local child1: integer = world:spawn(
    ChildOf(parent), tecs.ecs.RelativeTransform2D(20, 0)
)

local child2: integer = world:spawn(
    ChildOf(parent), tecs.ecs.RelativeTransform2D(-20, 0)
)

-- Walk children of a specific parent
world:targets(
    parent,
    ChildOf,
    function(childId: integer) print("child:", childId) end
)

-- Despawning parent cascades to child1 and child2
world:despawn(parent)

Events

local world = tecs.ecs.newWorld()

-- Define a custom event
local record DamageEvent is tecs.events.Event
    target: integer
    amount: number
    metamethod __call: function(
        self, target: integer, amount: number
    ): DamageEvent
end

-- Wire up the event init hook (it mutates a pre-allocated instance)
DamageEvent.init = function(
    e: DamageEvent, target: integer, amount: number
)
    e.target = target
    e.amount = amount
end
tecs.events.newEvent(DamageEvent)

-- Observe events anywhere in your game (0 = world-level)
world:observe(
    0,
    DamageEvent,
    function(e: DamageEvent)
        local health: Health = world:get(e.target, Health)
        if health then
            health.current = health.current - e.amount
            if health.current <= 0 then
                world:despawn(e.target)
            end
        end
    end
)

-- Emit events from systems
world:emit(0, DamageEvent, enemyId, 25)

Reference

The host loads tecs before the entry file. A game can use these names without a require:

tecs.assets - loading bytes, images and sounds off the main thread
tecs.audio - voices, groups, keyed limits, fades, pitch, loop points, streaming, devices
tecs.data - typed stores, JSON, byte encodings, DEFLATE, transcoding, UTF-8, UUIDs, hashes and checksums
tecs.ecs - worlds, components, queries, systems, events and resources
tecs.events - typed events and address-based message buses
tecs.gfx - the camera, the components, the renderer, text, and the vocabularies below
tecs.input - gameplay input, gamepads and standalone sensors
tecs.io - binary I/O, nonblocking sockets, HTTP, and external tools
tecs.log - named, leveled platform logging
tecs.math - angle math and two-dimensional geometry
tecs.physics - Rapier 2D, solved across a shared thread pool
tecs.platform - platform events, operating-system services, time, and windows
tecs.regex - compiled regular expressions over Lua byte strings
tecs.runtime - process-wide polling for asynchronous work
tecs.sequence - timelines with the tween runtime inside them
tecs.ui - retained layout, scrolling, clipping, and interaction over existing drawing components
tecs.workers - typed background jobs

Inside one of those, one level and no deeper:

tecs.data.utf8 - UTF-8 codepoint decoding, encoding, validation and truncation
tecs.ecs.random - seeded named streams and standalone generators
tecs.gfx.animation - sprite sheets, and the playback that reads them
tecs.gfx.layers - z-ordering and per-layer behavior
tecs.gfx.materials - one fragment shader, compiled from the material set
tecs.gfx.particles - emitters
tecs.io.files - where a game may read and write, and what to do with a path
tecs.io.http - fetching over HTTP without stopping the frame
tecs.io.mcp - the debug server agents and humans drive a running game through
tecs.io.Path - immutable UTF-8 paths with platform-native component rules
tecs.io.Process - streaming child processes with backpressured standard I/O
tecs.io.URI - immutable general-purpose URIs with component-aware modification
tecs.io.watcher - watching files for change
tecs.math.noise - native procedural scalar fields and bulk grids
tecs.math.vec2 - allocation-free two-dimensional vector and point math
tecs.platform.events - typed platform events routed through the world
tecs.platform.os - capabilities, process signals, the clipboard, and desktop services
tecs.platform.time - clocks, calendar time, delays and frame timing
tecs.platform.window - the window, its size, its display and its mode

On tecs itself, because no one module owns them:

tecs.Application - the object an entry file returns, and what the host drives
tecs.Future - a value that settles once
tecs.newApplication - builds the application an entry file returns
tecs.scoped - closes explicitly owned resources when one callback ends
tecs.Transform2D - where an entity is, and the one component every subsystem moves
tecs.Transform3D - a right-handed 3D position, orientation, and scale
tecs.version - the version of this build, as a string

tecs.ecs

Worlds, components, queries, systems, events and resources. One table with two ways in: a game reads it off tecs like any other module, and an engine module writes require("tecs.ecs"), because tecs is the aggregator that pulls every engine module in and a module tecs exports cannot also depend on tecs. These are the concepts behind the names.

Overview - the model, in one page
Archetypes - cache-friendly storage for millions of entities
Builtins - names, transforms, hierarchy, TTL, pause, disable, state events
Bundles - reusable entity templates and batch spawning
Components - table, tag, scalar and FFI data containers
Dirty tracking - change-gated systems and GPU synchronization
Events - type-safe pub/sub and entity lifecycle events
Mutation model - the normative rules for reads, writes and dirty bits
Phases - ordered phase scheduling
Plugins - modular, shareable game mechanics
Profiling - where a frame went
Queries - reusable filters with archetype iteration, callbacks and grouping
Relationships - links, hierarchies, relative transforms, cascade deletion
Save games - snapshots, component codecs, migrations, resource handlers
States - stack-based game states with transition events
Systems - phase scheduling, dependencies and run conditions
World - entities, resources and the state stack
